9047 Full Surface Strap Hinge

  • • Full surface strap hinge with butt type pintle pintle leaf for mounting to the face of the opening frame, pintle pin located at the edge of the opening.
  •
  • • Use hinge back plates when bolting through non-reinforced doors.

1) Type of Bearing

Ball Bearing Image
 Ball Bearing: Manual or power operation with an expected usage in excess of 20 cycles per day.
Disc Bearing Image
 Disc Bearing: Manual operation only with an expected usage of a maximum of 20 cycles per day.

2) Door Dimensions

  • a. Wdith of the door in feet (ft):    {Example: 3'-4" = 3.34 ft}
  • b. Height of the door in feet (ft):
  • c. Weight of the door in pounds (lbs.):

3 Results
