Features
Features
For by-passsing applications. Used on Eichler Sliding Garage Doors.
Max. Door Thickness: 1-3/4"
Max. Door Weight each door: 150 lbs.
Sold as a pair (2 ea.)
Documents & Downloads
Documents & Downloads
.pdf Drawing
4Z-F.stp fileTechnical Data
Technical Data
Purpose:
For manually operated sliding doors mounted in parallel (by-passing) in a single run of #4 box track.
Doors to be no thicker than 1-3/4" weighing up to 150 lbs. each.
An excellent replacement option for Eichler Sliding Garage Door Hardware.
Fasteners Included: (8 ea.) 1/4"-20 x 2-1/2" Countersunk Flat Head Machine Screws with Flat Washers, Lock Washers, and Nuts.
Material: 2-1/8" diameter steel ball bearing wheels.
